Chapter 53 — Configure Azure AD SAML Profile & Authentication Profile

Explicit Proxy requires SAML authentication for typical browser-based mobile users — this chapter outlines the two-step process: configuring a SAML Enterprise Application in Azure AD, then importing Azure AD's metadata into Panorama to create a SAML IdP profile and authentication profile. (Kerberos is a separate, currently-supported alternative for servers, IoT, and headless devices rather than typical browser users — see Chapter 49; SAML remains the right choice for the scenario this chapter covers.)

Chapter 54 covers the Azure AD configuration steps in detail.

⚠️ This chapter documents the direct SAML IdP import approach — confirmed still valid, but not the currently-recommended path for Azure AD specifically. Palo Alto's own documentation has a page titled "Configure Mobile Users using Cloud Identity Engine (Recommended)" for Azure AD SAML setups (covering both GlobalProtect and Explicit Proxy). That path is a genuinely different workflow, not just an alternate connection method for the same two steps: SP metadata is sourced from Cloud Identity Engine rather than from Prisma Access, and the authentication profile is created inside CIE, then referenced from Prisma Access — rather than importing Azure's metadata directly into a Panorama/SCM SAML IdP Profile the way this chapter does. Palo Alto also documents a sibling "Configure Mobile Users without Cloud Identity Engine" path, confirming this chapter's direct approach remains valid and supported — just not the one currently labeled "Recommended." This echoes the same direct-vs-CIE pattern Chapter 43 found for LDAP, and relates to Chapter 33's Identity Redistribution finding — CIE is Palo Alto's broader push toward a centralized identity broker across multiple authentication contexts, not something specific to this one chapter. Full CIE setup is out of scope here — see the CIE Azure AD configuration documentation if you want the recommended path instead.

Overview — Two-Step Process

flowchart TD
    S1["Step 1<br/>Configure SAML<br/>in Azure AD<br/>(ch54)"]
    S2["Download<br/>Metadata XML<br/>from Azure AD"]
    S3["Step 2<br/>Import Metadata XML<br/>to Panorama SAML IdP Profile"]
    S4["Create Authentication Profile<br/>in Explicit_Proxy_Template"]
    S5["Commit & Push<br/>→ Explicit Proxy"]

    S1 --> S2 --> S3 --> S4 --> S5

Step 1 — Configure SAML in Azure AD

Full step-by-step in Chapter 54. The key outputs from the Azure AD configuration are:

Step 2 — Import Metadata XML into Panorama

Navigation (Panorama): Panorama > Device > Server Profiles > SAML Identity Provider > Import

Navigation (Strata Cloud Manager) — confirmed via direct fetch: Configuration > NGFW and Prisma Access > Configuration Scope > Prisma Access > Mobile Users > Explicit Proxy Setup > User Authentication > SAML IdP Profile > Add SAML IdP Profile > Import — the same shared UI pattern used for GlobalProtect's SAML setup ("Select GlobalProtect Setup or Explicit Proxy Setup").

After import, Panorama auto-populates: - Identity Provider ID (Entity ID from Azure AD) - Identity Provider SSO URL (Azure AD SAML sign-on endpoint) - Identity Provider SLO URL (Azure AD sign-out endpoint) - IdP certificate (from the metadata XML)

📷 PaloAlto screenshot — SAML Identity Provider profile after metadata import

Step 3 — Create Authentication Profile

The authentication profile must be created within the Explicit_Proxy_Template context — not in the global Device context.

Navigation (Panorama): Panorama > Device > Authentication Profiles > Add (with Explicit_Proxy_Template selected in the template drop-down)

Navigation (Strata Cloud Manager) — confirmed, and confirmed to differ from Chapter 43's LDAP path, not assumed identical: Configuration > NGFW and Prisma Access > Configuration Scope > Prisma Access > Identity Services > Authentication > Authentication Profiles

This uses the same Identity Services > Authentication > Authentication Profiles structure Chapter 43 established for GlobalProtect's LDAP authentication profile — but scoped under Prisma Access, not Access Agent as Chapter 43's LDAP path was. Don't assume the two are interchangeable — the underlying screen structure is shared, but the configuration scope differs.

⚠️ If the authentication profile is created in the wrong template context, it will not be available during Explicit Proxy onboarding. Verify the template selector before saving.

📷 PaloAlto screenshot — Authentication profile in Explicit_Proxy_Template

Commit & Push

After creating the SAML IdP profile and authentication profile:

1. Commit > Commit and Push
2. Edit Selections → Select Prisma Access → Explicit Proxy
3. Click OK → Commit and Push

Strata Cloud Manager: Commit is replaced with Push Config, per the terminology already established in Chapter 28 — not re-explained here.

Key Takeaways

• SAML configuration is a two-step process: Azure AD setup (ch54) → Panorama import
• Entity ID must be https://global.acs.prismaaccess.com/saml/metadata — this is fixed, not configurable
• ACS URL must be https://global.acs.prismaaccess.com/saml/acs — also fixed
• Metadata XML import auto-populates the Panorama SAML IdP profile fields
• Authentication profile must be created inside Explicit_Proxy_Template — not globally
• Push scope must target Explicit Proxy, not Mobile Users or Service Setup
• This chapter's direct SAML import approach is confirmed still valid, but Palo Alto's docs explicitly recommend Cloud Identity Engine instead for Azure AD SAML — a genuinely different workflow (SP metadata sourced from CIE, auth profile created in CIE), not just an alternate connection method — see the CIE Azure AD docs if that path fits better
• Kerberos (Chapter 49) is a separate, currently-supported authentication option for Explicit Proxy — used for servers/IoT/headless devices, not the typical browser scenario this chapter covers
• SCM's Authentication Profile path uses the same Identity Services structure as Chapter 43's LDAP path, but scoped under Prisma Access rather than Access Agent — confirmed different, not assumed identical
